SNUFIT PA 220-150-35

The Snufit-PA 220 was designed for the ultra-light and light tanker integration. The system is currently being used on both Australian and international firefighting applications. The nature of the system design has allowed for easy adaption onto existing vehicles and incorporation into new vehicle designs.

The 150Lpm Compressed Air Foam deliverability is designed for fast response and preventative measures. The system also capable of standard firefighting tactics and the pump can produce 350Lpm at 8Bar water flow.

For more information about the Snufit 220, contact our Cafs Development team today.

Enquire Now
Category:

Specifications

  • Model:
    SNUFIT PA 220-150-35
  • Engine Specifications::
  • Type:
    Air cooled - Diesel
  • Manufacturer:
    Kolher
  • Model:
    CH440
  • Power:
    10.4 KW / 14HP
  • Speed:
    3600RPM
  • Voltage:
    12V
  • Water Pump Specifications::
  • Manufacturer:
    BELL FIRE
  • Model:
    MK1
  • Max Pressure:
    8.5 BAR
  • Max Water Flow:
    350 LPM
  • Wet Caf:
    150 LPM
  • Compressor System Specifications::
  • Manufacturer:
    MEA
  • Max Pressure:
    10 BAR / 150 PSI
  • Max Air Flow:
    35 CFM @ 10 BAR
